The Planetary Cycloidal Pinwheel Reducer stands as a masterclass in mechanical engineering, transforming raw motor power into precise, manageable kinetic energy. When you run your hand along its rugged, cast-iron and high-strength alloy steel housing, you immediately feel the industrial-grade durability built into every square inch. Inside, the precisely machined cycloidal gears mesh with fluid grace, producing a reassuringly smooth, low-decibel hum rather than the grating mechanical noise typical of lesser drives. This meticulously crafted internal geometry practically eliminates metal-to-metal dry friction, establishing a robust protective oil film that keeps the system running cool even under punishing, continuous-duty operations. By integrating this advanced speed reducer into your automated lines or heavy machinery, you instantly upgrade your operational stability. It effortlessly tames massive inertial loads, ensuring your equipment operates with pinpoint accuracy and unyielding reliability. The tactile sensation of its vibration-free operation and the visual assurance of its leak-proof seals provide absolute confidence, ultimately safeguarding your production schedules and minimizing unexpected mechanical downtime.
Technical Parameters
| Input power | 0.09kw~173kw |
| Output torque | 20N.m~60800N.m |
| Transmission ratio | 6~658503 |
| Price | 490~130000 yuan |
 |  |  |  |  |
 |  |  |  |  |
Explore the distinct advantages that make our cycloidal reducers the preferred choice for demanding industrial environments. We focus on continuous innovation to bring you a drive solution that outlasts and outperforms conventional gearboxes, ensuring your machinery operates at peak efficiency.
Exceptional Load Capacity: The unique internal geometry distributes stress across multiple cycloidal pins simultaneously, absorbing massive shock loads without compromising structural integrity.
Thermal Dissipation Excellence: The engineered finned exterior design accelerates heat transfer, keeping internal temperatures within optimal thresholds during round-the-clock operations.
Zero-Leakage Sealing: Equipped with premium rotary shaft seals that lock in vital lubrication and completely lock out abrasive dust, moisture, and chemical contaminants.
Vibration Dampening: The inherently balanced planetary motion neutralizes harmonic vibrations, protecting your sensitive downstream components from mechanical fatigue.
Achieving peak operational efficiency requires a drive system that refuses to compromise on precision or power. Our cycloidal reducers are engineered to dominate high-stress environments, providing the exact mechanical control necessary for modern automated systems.
Ultra-Low Backlash: Meticulously engineered to maintain a backlash of less than 3 arcminutes, guaranteeing exact positioning and repeatability for highly sensitive automated tasks.
Massive Torque Output: Capable of delivering a staggering 60,800 N.m of output torque, effortlessly driving the most demanding heavy machinery without stalling or slipping.
High Transmission Efficiency: The rolling friction mechanism drastically reduces energy loss compared to traditional sliding friction, translating more input power directly into usable mechanical force.
Space is a premium in modern facility layouts. We designed this reducer with a highly adaptable, compact footprint to integrate seamlessly into your existing infrastructure, reducing installation headaches and spatial conflicts.
Modular Architecture: Allows for rapid assembly and seamless integration with various motor types, streamlining your installation process and reducing engineering time.
Versatile Mounting Configurations: Choose from vertical, horizontal, flange, or hollow shaft installations to perfectly match your spatial constraints and mechanical requirements.
Space-Saving Profile: The concentric shaft design packs immense reduction ratios into a fraction of the volume required by traditional parallel shaft gearboxes, freeing up valuable floor space.
A speed reducer is only as reliable as the materials from which it is forged. We utilize uncompromising metallurgical standards to ensure decades of dependable service, even in the most hostile industrial environments.
High-Strength Alloy Steel: Core transmission components are forged from premium alloy steel, offering unparalleled resistance to mechanical fatigue and shearing forces.
Hard-Tooth Surface Treatment: Advanced thermal processing hardens the gear surfaces, drastically reducing wear and tear even under continuous, abrasive operating conditions.
Rugged Cast Iron Housing: The heavy-duty outer shell provides a fortress-like enclosure, shielding delicate internal mechanisms from severe industrial impacts and corrosive ambient elements.
Different sectors face unique mechanical challenges, but the need for reliable power transmission is universal. This reducer is specifically tailored to meet the strict demands of highly specialized fields where failure is not an option.
Robotics & Automation: Provides the exact articulation and smooth motion control required for robotic joints, ensuring fluid and precise movements.
CNC Machining: Ensures tool heads and workpieces maintain flawless alignment under heavy cutting loads, directly improving the surface finish of machined parts.
Heavy Metallurgy & Mining: Built tough enough to survive the extreme dust, intense heat, and severe shock loads inherent in mineral processing and metal forging.
Packaging & Logistics: Delivers the rapid start-stop reliability necessary for high-throughput sorting conveyors and automated packaging machinery.
We believe that maintaining your equipment should be straightforward and predictable. Proper care ensures your reducer operates at peak efficiency for years. Understanding the basis for bearing replacement and lubrication management is crucial to protecting your investment and preventing catastrophic failures.
Crucial Lubrication Management: Never operate the reducer without proper oil! During operation, high-quality lubricating oil forms an extremely thin, protective oil film at the contact positions of rotating parts such as bearings. This critical barrier prevents hard-to-hard, iron-to-iron dry friction. Operating dry will instantly damage bearings and transmission components like gears and gear shafts.
Thermal Monitoring: When the reducer is operating, closely monitor the temperature. If the bearing position becomes abnormally hot to the touch, stop the machine immediately to check if the bearing is damaged. A compromised bearing must be replaced instantly; continuing operation will cause cascading damage to other internal components and result in significant financial losses.
Acoustic Diagnostics: Listen to your equipment. If the bearing position begins making an abnormal noise—similar to a rattling or grinding sound—halt operations. While a damaged bearing is a likely culprit requiring immediate replacement, pay attention to whether the noise might actually be the sound of gear meshing. Because this acoustic diagnosis can be complex, we highly recommend consulting with our expert technical team to make a joint determination.
Trust is built on verifiable quality. Every single unit that leaves our facility undergoes a rigorous gauntlet of inspections to guarantee flawless performance and absolute consistency across your entire fleet of machinery.
Global Standard Certifications: Fully compliant with ISO9001, CE, and RoHS standards, ensuring the product meets strict international safety, quality, and environmental benchmarks.
Precision CNC Machining: Manufactured using state-of-the-art CNC equipment, guaranteeing that every pinwheel and cycloidal disc is cut to microscopic tolerances for perfect meshing.
Comprehensive Testing: Each reducer is subjected to dynamic load testing, acoustic emission analysis, and thermal imaging before it is approved for dispatch, ensuring out-of-the-box reliability.
Off-the-shelf solutions do not always fit complex engineering problems. We provide comprehensive customization and support to align exactly with your project specifications, ensuring a perfect mechanical fit.
Flexible OEM/ODM Capabilities: From custom shaft dimensions to specialized anti-corrosion paint coatings, we adapt our manufacturing lines to produce exactly what your blueprints dictate.
Expert Selection Support: Our dedicated engineering team works alongside your technical staff to calculate load requirements and select the perfect reduction ratio for your application.
Responsive Global Support: Access detailed technical documentation, troubleshooting guides, and rapid replacement parts through our extensive international service network.
Partnering with the right manufacturer is a critical strategic decision. We bring decades of specialized expertise to your supply chain, ensuring you receive more than just a piece of hardware—you receive a competitive advantage.
Direct-from-Source Economics: By eliminating intermediaries, we provide premium-grade drive technology at highly competitive price points, directly optimizing your project budgets.
Unwavering Consistency: Our standardized production protocols mean that whether you order one unit or one hundred, every single reducer performs identically, ensuring predictable integration.
Rapid Fulfillment: Maintaining extensive inventories of core components allows us to assemble and dispatch large volume orders with industry-leading speed, keeping your projects on schedule.
Dedicated Engineering Partnership: We do not just supply parts; we supply solutions. Our technical team is always on standby to assist with complex integration challenges and lifecycle management.
To maintain the integrity of the internal oil film and prevent thermal degradation of the rotary seals, the ambient operating temperature should ideally remain between -10°C and 40°C. If your application requires operation outside this window, we can equip the unit with specialized synthetic lubricants and high-temperature Viton seals to ensure continuous reliability.
Unlike traditional involute gears that rely on sliding friction and have limited tooth contact, our cycloidal design utilizes rolling friction. At any given time, up to 67% of the cycloidal disc's lobes are engaged with the ring gear pins. This massive, distributed contact area allows the unit to absorb shock loads up to 500% of its rated torque without catastrophic failure.
Yes, the unit is highly versatile and supports vertical mounting. However, vertical installations (especially shaft-up configurations) require specific lubrication arrangements, such as forced oil pumps or specialized grease packing, to ensure the uppermost bearings do not run dry. Please specify your exact mounting orientation during the ordering process so we can configure the internal lubrication system accordingly.
The first 300 hours of operation are critical for the long-term health of the reducer. During this break-in phase, microscopic metallic particles may shed as the gears mate perfectly. We strictly mandate a complete oil drain, an internal flush, and replacement with fresh, filtered lubricant immediately after this initial period to ensure long-term, whisper-quiet operation.
Selecting the right ratio involves precisely calculating your required output speed and the maximum continuous torque demands of your driven load. You must also factor in the ""service factor"" based on your daily operational hours and the frequency of shock loads. Our engineering team is readily available to run these complex calculations for you, guaranteeing an optimal and safe mechanical match.
